As many of you know there has been an Echolink enabled repeater in the area for some time now. Over the Christmas Holiday and all the way thru now there has been a considerable amount of time put in to the underlying mechanics, the computer system. Echolink is standard windows program, which is an easily operated point and click operation, but as with anything windows is not stable long term, in other words it works great until enough time goes by then it doesn’t. So as with everything else in my shack I switched it over to a Linux based program. In the case of Echolink, the program I use is SVXLink. Over this long period, I have learned much about configuring this program and right along with it how to work in Linux, it was one of the best learning experiences I have had with the computer.

SVXLink is a very powerful piece of software, not only can it do Echolink, it can act as a repeater controller, a cross band link if needed, a weather machine, it will do a lot. Right now, it serves to link the 444.750 machine to the Nebraska Hub. The Nebraska hub has been a growing network of Nebraska linked repeaters. The link is established thru the KD0PGV link, which unfortunately at the time of this writing is down for repairs, but for the better part of a year it has been flawless. Should be back linked soon we hope. In the mean time I wanted to write a piece that gives instructions on how to link with other machines. SVXLink has a little different way of doing things than the standard Echolink software.

I will just give the codes here and what they do:

* SVXLink Status

1# Link Status

# Disconnect

If you have to deactivate the Echolink module you can re-connect by dialing 2#

If the Echolink Module is not loaded it will not recognize your commands.

For any node, enter the node number followed by the # key. Shortcuts to favorite destinations follows. If you have a favorite Echolink node that you want a shortcut added for then let us know and it can be added.

D1# Nebraska Hub – Non Operational

D2# kr1sto North platte

D3# N0IQ North platte

D4# WB0WLY Omaha area Linked repeaters

D5# Crossroads reflector

D6# Dodropin reflector

D7# Hi-Gate reflector

D8# Handiham reflector

D9# open

D10# kd0an

D11# kc0swg

D12# kd0efc

D13# Michigan – These people are a bit of a bunch of jackasses, so no kerchunking or anything out of the ordinary please. And if anyone connects here and hears something that should not be there please report it to the Sysop.

D14# World reflector

D15# USA

D16# KC0EQA – Hastings, NE – Possibly connected to the Allstar Network

As many of you know a few were honored to attend a training session put on by the department of homeland security called Auxcom. It was training to to help the ham community and other radio services learn to communicate when disasters happen. The old saying is hams will work when nothing else does, this is true, but there is so much more to it than that and this course helped us to understand the many different services we can provide and how we provide that service. It is also our responsibility to help the emergency service providers understand who we are, what we are capable of, and how we can use those capabilities to help them save lives. Many of have had other training to be more involved and can be an important tool when it comes to saving lives.

We live in a region where we are relatively blessed with tranquility most of the time. We normally do not have major destructive storms like they have in the south, we generally are not a target of terrorism, and we are not a major industrial area. However, any and all of these thing could happen here. We have two major rail lines that pass thru GI, we have a blossoming ethanol industry, and we have seen the destructive power of tornadoes here. It is incumbant on all of us to take these possibilities seriously and we as a club need to get ourselves organized. If participation is low that we need to find a way to get others involved.

So with that, here are a few things we should start doing right away. We need to write and adopt a SOP, one that has been written with the knowledge and input of our emergency personal whom we will be working with, Agreements should be obtained with our sister clubs on use of equipment, and a general training regimen should be instituted.

There is a lot we can do to help. But it does take a little bit of commitment. You will as a ham, have to have credentials. You will have to pass background checks. In today’s day and age, with liability and all that goes with putting yourself out there,  just showing up in an emergency is likely not going to be useful to anyone. Our emergency people cannot let you get involved in the process if you are not trained and credentialed in some way.

As all of this goes forward, we would encourage everyone’s participation. Consider all of this an upgrade on what we have already been doing. Think of it like this, what we are doing now is bringing our organization in line with ICS/NIMS and other Homeland security procedures. Being able to bring our procedures up to date, and our training up to date, and doing it as a club will allow us to operate in a proficient and useful manner with a high degree of professionalism.

We welcome your comments and look forward to talking about and working on it together. See you all on Thursday.
